Specifications
AMC Gremlin X and Spirit AMX
AMC Gremlin X and Spirit AMX factory specifications: 38 sourced across 3 model years, 1976–1980.
38 specifications · 0 sources
1976
| Measure | Value | Applies to |
|---|---|---|
| Length | 169.4 in | Gremlin (one figure printed for the model) |
| Wheelbase | 96 in | Gremlin (one figure printed for the model) |
| Width | 70.6 in | Gremlin (one figure printed for the model) |
| Height | 52.3 in | Gremlin (one figure printed for the model) |
| Tread, front / rear | 57.5 / 57.1 in | Gremlin (one figure printed for the model) |
| Turning diameter (wall to wall) | 35.3 ft | Gremlin (one figure printed for the model) |
| Head room, front / rear | 38.0 / 36.4 in | Gremlin (one figure printed for the model) |
| Leg room, front / rear | 40.7 / 29.2 in | Gremlin (one figure printed for the model) |
| Shoulder room, front / rear | 54.9 / 53.0 in | Gremlin (one figure printed for the model) |
| Hip room, front / rear | 54.9 / 53.0 in | Gremlin (one figure printed for the model) |
| Cargo volume index | 26.9 cu ft | Gremlin, with rear seat down (page footnote) |
| Cargo floor length | 50.4 in | Gremlin, with rear seat down (page footnote) |
| Fuel tank | 21 gal | Gremlin (one figure printed for the model) |
| Vehicle curb weight (approx.) | 2,831 lb | Gremlin (one figure printed for the model) |
| Bore x stroke | 3.75 x 3.50 in | 232 CID six |
| Bore x stroke | 3.75 x 3.90 in | 258 CID six |
| Bore x stroke | 3.75 x 3.44 in | 304 CID V-8 |
| Compression ratio | 8.0:1 | 232 CID six and 258 CID six (1-barrel) |
| Compression ratio | 8.4:1 | 304 CID V-8 (2-barrel) |
| Exhaust system and fuel required | Single exhaust; unleaded fuel | 232 CID six, 258 CID one-barrel six and 304 CID V-8 |
| Three-speed manual gear ratios (1st / 2nd / 3rd; reverse) | 2.99 / 1.75 / 1.00; 3.17 :1 | AMC three-speed manual, 1976 ratios (line-wide table; the manual is standard on the Gremlin) |
| Overdrive final drive ratio | .778 :1 | Laycock J-type overdrive, AMC 232 and 258 sixes with manual transmission |
| Torque-Command automatic gear ratios (1st / 2nd / 3rd; reverse) | 2.45 / 1.45 / 1.00; 2.20 :1 | 1976 AMC Torque-Command automatic (line-wide table) |
| Axle ratios, standard / (optional) | Manual and manual with overdrive: 2.73 / (3.08). Torque-Command automatic, column or floor: 2.73 / (3.08) and (2.53). Footnote: 3.08 is the standard axle ratio in California on all 6-cylinder Gremlins. :1 | 232 CID six and 258 CID six |
| Axle ratios, standard / (optional) | Manual: 3.15 standard, optional printed as (2.87)** (3.15)***. Torque-Command automatic, column or floor: 2.87 standard, (3.15) optional. Footnotes: ** N.A. in California; *** 3.54 is the optional ratio in California. :1 | 304 CID V-8 (manual row quoted as printed, including the optional 3.15 shown beside a 3.15 standard) |
| Tire 6.45 x 14 black (white line optional) | Standard with six-cylinder engines; N.A. with V-8s | Gremlin |
| Tire 6.95 x 14 black (white line optional) | Optional with six-cylinder engines; standard with V-8s | Gremlin |
| Optional tires (sixes and V-8s) | D78 x 14 white line; D70 x 14 black (white letter optional); DR70 x 14 radial (steel) white letters; DR78 x 14 radial (steel) black; DR78 x 14 radial (steel) white line. Footnote: D78 x 14 is the minimum tire required with styled road or aluminum wheels. | Gremlin |
1979
| Measure | Value | Applies to |
|---|---|---|
| Wheelbase | 96 in | AMX |
| Overall length | 168.5 in | AMX |
| Overall width | 71.8 in | AMX |
| Overall height | 51.6 in | AMX |
| Track, front / rear | 58.1 / 57.5 in | AMX |
| Cargo volume | 24.8 cu ft | AMX |
| Curb weight | 2,970 lb | AMX |
| Axle ratios (49 states / California / high altitude) | 258 4-speed 2.53 / 2.73 / 2.53; 258 automatic 2.53 / 2.73 / 2.73; 304 4-speed 2.87 / NA / NA; 304 automatic 2.56 / NA / 2.87 (2.87 with Twin-Grip) :1 | AMX |
1980
| Measure | Value | Applies to |
|---|---|---|
| Engine | 4.2 liter (258 CID) 2V six, 8.3:1, 3.75 x 3.90 in (only AMX engine) | AMX |
| Axle ratio | 2.53 (2.73 high altitude with automatic) :1 | AMX |
Each year's heading links to that model year's full fact sheet. Specification labels are carried as recorded and not normalized across years, so the same measure may be worded differently from one year to the next.
