Specifications
Rambler and AMC Marlin
Rambler and AMC Marlin factory specifications: 19 sourced across 3 model years, 1965–1967.
19 specifications · 2 sources
1965
| Measure | Value | Applies to |
|---|---|---|
| Wheelbase | 112 in | 1965 Marlin (Classic platform) |
| Overall length | 195 in | all 1965 Marlins |
| Loaded height | 54.2 in | all 1965 Marlins |
| Width | 74.5 in | all 1965 Marlins |
| Tread, front / rear | 58.6 / 57.6 in | all 1965 Marlins |
| Brakes | 11.2-in front discs, 10-in rear flanged drums, power assisted (standard) | all 1965 Marlins |
| Tires | 7.35 x 14 (7.75 x 14 optional for V-8s) | all 1965 Marlins |
| Fuel tank capacity | 19 US gal | all 1965 Marlins |
| Axle ratios | 232: 3-speed 3.15, overdrive 3.54, Flash-O-Matic 3.15; 287: 3-speed 3.54, overdrive 3.54, Flash-O-Matic 2.87 (3.15 no-cost); 327: 3-speed 3.54, overdrive 3.54, Flash-O-Matic 3.15 (2.87 no-cost); floor Twin-Stick 3.54; floor Shift-Command 3.15 (V-8 2.87 no-cost) :1 | all 1965 Marlins |
1966
| Measure | Value | Applies to |
|---|---|---|
| Wheelbase | 112 in | 1966 Marlin |
| Overall length | 195 in | 1966 Marlin |
| Loaded height | 54.2 in | 1966 Marlin |
| Width | 74.5 in | 1966 Marlin |
| Tread, front / rear | 58.2 / 57.4 in | 1966 Marlin |
| Brake diameter / lining area | 10 / 167.5 in / sq in | 1966 Marlin |
| Tires | 7.35 x 14 (7.75 x 14 optional for V-8s) | 1966 Marlin |
| Fuel tank capacity (approx.) | 19 US gal | 1966 Marlin |
1967
| Measure | Value | Applies to |
|---|---|---|
| Wheelbase | 118 in | 1967 Marlin |
| Axle ratios | 232: 3-speed column 3.15, overdrive 3.54, Flash-O-Matic 3.15; 290: 3-speed 3.15 (3.54), overdrive 3.54, Flash-O-Matic 3.15 (2.87), 4-speed 3.15 (3.54), Shift-Command 3.15 (2.87); 343: Flash-O-Matic, 4-speed and Shift-Command as 290; no 3-speed or overdrive with 343; 4-speed not with 2-bbl 343 :1 | 1967 Marlin |
Each year's heading links to that model year's full fact sheet. Specification labels are carried as recorded and not normalized across years, so the same measure may be worded differently from one year to the next.
