Specifications
Chrysler 300 SRT
Chrysler 300 SRT factory specifications: 56 sourced across 9 model years, 2006–2023.
56 specifications · 51 sources
2006
| Measure | Value | Applies to |
|---|---|---|
| Standard equipment (feature availability) | HID xenon headlamps with washers; rear deck spoiler; integrated brake-duct fascias; automatic dual-zone climate control; 180-mph speedometer; tire-pressure monitoring display; memory for radio, seats, mirrors and power pedals; power sport seats with performance suede inserts, heat and memory; Boston Acoustics speakers with six-disc CD changer; Brembo four-piston brakes; ESP tuned for SRT; rear park assist; five-spoke 20-inch forged wheels with Goodyear F1 three-season tires | 300C SRT8 |
| Brake rotors (Brembo four-piston) | 360 x 32 mm front, 350 x 28 mm rear, vented mm | 300C SRT8 |
| Tires | Goodyear F1 245/45R20 front, 255/45R20 rear on 20-inch forged wheels | 300C SRT8 |
2007
| Measure | Value | Applies to |
|---|---|---|
| Engine | 6.1-liter HEMI V-8, 370 cu in (6,059 cc), 4.06 x 3.58 in, 10.3:1; 425 bhp (317 kW) at 6,000 rpm and 420 lb-ft at 4,800 rpm (estimated SAE net); 6,400 rpm limit | 300C SRT8 |
| Transmission | W5A580 five-speed automatic with AutoStick: 3.59 / 2.19 / 1.41 / 1.00 / 0.83, reverse 3.17; final drive 3.06; overall top gear 2.54 | 300C SRT8 |
| Dimensions | Wheelbase 120.0; track 63.0 / 63.1; length 196.8; width 74.1; height 57.9; ground clearance 5.1 in | 300C SRT8 |
| Curb weight (estimated) | 4,160 (1,888 kg); 55/45 front/rear lb | 300C SRT8 |
| Fuel tank / EPA fuel economy | 19 gal / 14 city, 20 highway mpg | 300C SRT8 |
| Steering | Rack and pinion with hydraulic assist, 16.1:1, 2.75 turns lock to lock, 38.9 ft turning diameter | 300C SRT8 |
| Assembly | Brampton, Ontario, Canada; introduced April 2005 as MY2006 | 300C SRT8 |
2008
| Measure | Value | Applies to |
|---|---|---|
| Standard equipment new for 2008 | Adaptive Cruise Control (standard; ESP tuned for it); SRT Reconfigurable Display in the cluster; deck lid with integrated spoiler; revised instrument panel and center console; ride height one-half inch lower than the 300C | 300C SRT8 |
2009
| Measure | Value | Applies to |
|---|---|---|
| Standard equipment changes for 2009 | Power sunroof now standard; uconnect tunes standard; new front-seat head rests; new front grille; brake knockback mitigation software | 300C SRT8 |
2010
| Measure | Value | Applies to |
|---|---|---|
| Engine | 6.1-liter HEMI V-8, 90-degree, 370 cu in (6,059 cc), bore x stroke 4.06 x 3.58 in (103.0 x 90.9 mm), pushrod overhead valve, 16 valves, hydraulic roller lifters, sequential multiport returnless fuel injection, deep-skirt cast-iron block with cross-bolted mains, aluminum heads, 10.3:1 compression; 425 bhp (317 kW) at 6,000 rpm (69.8 bhp/L); 420 lb-ft (569 N-m) at 4,800 rpm; 6,400 rpm electronic limit | 300C SRT8 |
| Fuel, fluids and emissions | Premium 91 octane recommended; engine oil 7 qt (6.6 L) SAE 5W-40 synthetic; coolant 14 qt (13.25 L); fuel tank 19 gal (72 L); dual close-coupled three-way catalysts with quad heated oxygen sensors; not rated for trailer towing; EPA fuel economy 13 city / 19 highway mpg | 300C SRT8 |
| Transmission and axle ratios | W5A580 five-speed automatic, adaptive electronic control, AutoStick, electronically modulated converter clutch: 3.59 / 2.19 / 1.41 / 1.00 / 0.83, reverse 3.17; final drive 3.06; overall top gear 2.54 | 300C SRT8 |
| Electrical | 160-amp alternator; H7 battery, 730 cold-cranking amps | 300C SRT8 |
| Exterior dimensions | Wheelbase 120.0; length 196.8; width 74.1; height 57.9 (58.5 with SDAR antenna); track 63.0 front / 63.1 rear; ground clearance 5.1 in | 300C SRT8 |
| Weight and aerodynamics | Curb weight (estimated) 4,160 lb (1,888 kg); weight distribution 55/45 as printed; frontal area 25.8 sq ft (2.40 sq m); drag coefficient 0.355 | 300C SRT8 |
| Interior room | Front: head 38.7, leg 41.8, shoulder 59.4, hip 55.9; rear: head 38.0, leg 40.2, knee 4.8, shoulder 57.7, hip 55.9; SAE volume front 55.6 cu ft (1.58 cu m), rear 51.0 (1.44); total interior volume 106.6 (3.00); SAE cargo 15.6 (0.442); EPA interior volume index 122.2 (3.46); trunk lift-over 30.2 (768 mm) in unless stated | 300C SRT8 |
| Body and suspension | Unitized steel body; front independent short/long arm with high upper A arm, coil-over gas monotube Bilstein shocks and stabilizer bar; rear independent five-link with coil springs, link-type stabilizer bar, Bilstein monotube shocks and isolated cradle; SRT-tuned dampers; ride height lowered 0.5 in compared with the 300C | 300C SRT8 |
| Steering | Rack-and-pinion, hydraulic power assist; ratio 16.1:1; turning diameter 38.9 ft (11.9 m); 2.75 turns lock to lock | 300C SRT8 |
| Wheels and tires (engineering guide) | Forged polished aluminum wheels, 20 x 9 in; standard P245/45ZR20 all-season Goodyear Eagle RS-A tires (729 revs/mile front, 720 rear); optional P245/45ZR20 three-season Goodyear F1 Supercar tires (729 front, 720 rear) | 300C SRT8 |
| Wheels and tires (sales brochure) | Standard P245/45R20 All-Season Performance tires (as printed) on 20-in Ultra-Brite Aluminum SRT design wheels, with a tire service kit; optional row printed 'P245/45R20, 255/45ZR20 Performance' | 300C SRT8 column |
| Brakes | Brembo four-piston fixed calipers; front 14.2 x 1.26 in (360 x 32 mm) vented rotor, 1.73 in (44 mm) pistons, swept area 351 sq in (2,261 sq cm); rear 13.8 x 1.10 in (350 x 28 mm) vented rotor, 1.26 in (32 mm) pistons, swept area 316 sq in (2,036 sq cm); four-wheel ABS and traction control, electronic stability control and Brake Assist standard; 8 x 9 in (203 x 229 mm) tandem-diaphragm vacuum booster; brake-knockback mitigation software | 300C SRT8 |
| Standard exterior and comfort equipment | SRT8 decklid badging; body-color bumper inserts and door handles; integrated brake-duct fascias; xenon HID headlamps; integrated rear spoiler; power sunroof with one-touch open/close and vent; automatic dual-zone air conditioning with infrared sensors; HomeLink; 180-mph speedometer cluster; tire pressure monitoring; electronic vehicle information center with Performance Pages (0-60, eighth-mile and quarter-mile times, braking timers, G-meter); memory for radio, seats and mirrors; power-adjustable pedals with memory | 300C SRT8 (S marks) |
| Standard audio and connectivity | Boston Acoustics speaker system; SIRIUS Satellite Radio (marked standard in the guide; see conflicts); Uconnect Multimedia; leather steering wheel with chrome ferrules and audio controls. The brochure prints Media Center 430 with six Boston Acoustics speakers and a 276-watt amplifier as standard | 300C SRT8 |
| Safety equipment | Advanced multi-stage air bags; electronic stability control; energy-absorbing steering column; Keyless Entry / Keyless Go; LATCH child-seat anchors; occupant classification system; rear park assist; seat belts with constant force retractors and pretensioners; trunk internal release; HID headlamps. Supplemental side-curtain air bags are marked P in the guide, which names no package (the brochure prints them included; see conflicts) | 300C SRT8 |
| SRT Track Experience | Standard: a one-day event at the Richard Petty Racing School | 300C SRT8 (S mark) |
2012
| Measure | Value | Applies to |
|---|---|---|
| Engine | 6.4-liter HEMI V-8 with Fuel Saver Technology, 392 cu in (6,424 cc), 4.09 x 3.72 in, 10.9:1; 470 hp (351 kW) at 6,000 rpm and 470 lb-ft at 4,300 rpm (SAE J2723); 6,400 rpm limit; built at Saltillo Engine Plant, Mexico | 300 SRT8 |
| Transmission and axle | W5A580 five-speed automatic with AutoStick: 3.59 / 2.19 / 1.41 / 1.00 / 0.83, reverse 3.16; final drive 3.06 with Getrag limited-slip differential; overall top gear 2.54 | 300 SRT8 |
| Dimensions | Wheelbase 120.2; track 63.4 / 63.1; length 200.33; width 74.24; height 58.26 in | 300 SRT8 |
| Curb weight | 4,365 (1,979.7 kg); 54/46 front/rear lb | 300 SRT8 |
| Fuel tank / EPA fuel economy | 19.1 gal / 14 city, 23 highway mpg | 300 SRT8 |
| Brakes | Brembo four-piston fixed calipers; 14.2 x 1.26 in (360 x 32 mm) vented and slotted front rotors; 13.8 x 1.10 in (350 x 28 mm) vented and slotted rear rotors | 300 SRT8 |
| Wheels | 20 x 9.0 fully forged aluminum (Black Vapor Chrome finish optional) | 300 SRT8 |
| Assembly and introduction | Brampton Assembly Plant, Ontario, Canada; introduced summer 2011 as a 2012 model | 300 SRT8 |
2013
| Measure | Value | Applies to |
|---|---|---|
| Engine | 6.4-liter HEMI V-8 with Fuel Saver Technology, 392 cu in (6,417 cc), 4.09 x 3.72 in, 10.9:1; 470 hp (351 kW) at 6,000 rpm and 470 lb-ft at 4,300 rpm (SAE J2723); 6,400 rpm limit; built at Saltillo Engine Plant, Mexico | 300 SRT8 |
| Transmission and axle | W5A580 five-speed automatic with AutoStick: 3.59 / 2.19 / 1.41 / 1.00 / 0.83, reverse 3.16; final drive 3.06 with Getrag limited-slip differential; overall top gear 2.54 | 300 SRT8 |
| Dimensions | Wheelbase 120.2; track 63.4 / 63.1; length 200.33; width 74.24; height 58.26 in | 300 SRT8 |
| Curb weight | 4,365 (1,979.7 kg); 54/46 front/rear lb | 300 SRT8 |
| Fuel tank / EPA fuel economy | 19.1 gal / 14 city, 23 highway mpg | 300 SRT8 |
| Brakes | Brembo four-piston fixed calipers; 14.2 x 1.26 in (360 x 32 mm) vented and slotted front rotors; 13.8 x 1.10 in (350 x 28 mm) vented and slotted rear rotors | 300 SRT8 |
| Wheels | 20 x 9.0 fully forged aluminum (Black Vapor Chrome finish optional) | 300 SRT8 |
| Assembly and introduction | Brampton Assembly Plant, Ontario, Canada; introduced summer 2012 as a 2013 model | 300 SRT8 |
2014
| Measure | Value | Applies to |
|---|---|---|
| Engine | 6.4-liter HEMI V-8 with Fuel Saver Technology, 392 cu in (6,417 cc), 4.09 x 3.72 in, 10.9:1; 470 hp (351 kW) at 6,000 rpm and 470 lb-ft at 4,300 rpm (SAE J2723); 6,400 rpm limit; built at Saltillo Engine Plant, Mexico | 300 SRT (Core and Premium) |
| Transmission and axle | W5A580 five-speed automatic with AutoStick: 3.59 / 2.19 / 1.41 / 1.00 / 0.83, reverse 3.16; final drive 3.06 with Getrag limited-slip differential; overall top gear 2.54 | 300 SRT (Core and Premium) |
| Dimensions | Wheelbase 120.2; track 63.4 / 63.1; length 200.33; width 74.24; height 58.26 in | 300 SRT (Core and Premium) |
| Curb weight | 4,365 (1,979.7 kg); 54/46 front/rear lb | 300 SRT (Core and Premium) |
| Fuel tank / EPA fuel economy | 19.4 gal / 14 city, 23 highway mpg | 300 SRT (Core and Premium) |
| Brakes | Brembo four-piston fixed calipers; 14.2 x 1.26 in (360 x 32 mm) vented and slotted front rotors; 13.8 x 1.10 in (350 x 28 mm) vented and slotted rear rotors | 300 SRT (Core and Premium) |
| Wheels | 20 x 9.0 fully forged aluminum (Black Vapor Chrome finish optional) | 300 SRT (Core and Premium) |
| Assembly and introduction | Brampton Assembly Plant, Ontario, Canada; introduced summer 2013 as a 2014 model | 300 SRT (Core and Premium) |
2023
| Measure | Value | Applies to |
|---|---|---|
| Rear axle | 3.09 limited-slip ratio | 300C |
| Wheels and tires | 20 x 9-inch forged wheels with all-season performance tires | 300C |
| Chassis equipment | Red four-piston Brembo brakes; active damping suspension; active exhaust with black rounded tips; TorqueFlite eight-speed with 160-millisecond shifts | 300C |
| Standard equipment (fully equipped; no options listed) | 19-speaker Harman Kardon audio; 8.4-inch Uconnect with Android Auto and Apple CarPlay; heated steering wheel; heated and ventilated front seats; advanced brake assist; Lane Departure Warning Plus; Full Speed Collision Warning Plus; black chrome grille and lower-fascia accents; black headlamp and taillamp bezels; tri-color 300C badges on grille and decklid | 300C |
Each year's heading links to that model year's full fact sheet. Specification labels are carried as recorded and not normalized across years, so the same measure may be worded differently from one year to the next.
